The 700 SP rotary flow meter is designed to meter petroleum products such as gasoline, fuel oils, diesel, bio-diesel, kerosene, vegetable oils, soy oil, motor oils, ethylene glycol (anti-freeze), etc. It is available in 1.5" to 4" sizes.
700 SP Meter Specific
- Housing: Hardcoat Anodized Aluminum
- Rotors: Hardcoat Anodized Aluminum
- Rotor Journals: Plated Stainless Steel
- Bearing Plates: Ni-Resist
- Bearing Sleeves: Ni-Resist
- Timing Gears: Stainless Steel
- Packing Seal: FKM
- Body O-ring: FKM
All 700 Meters
- Flow: Capable of up to 1,000 GPM (3,785 LPM); Bi-directional Flow
- Linear Accuracy: Capable of ± 0.15% of over the full flow range
- Repeatability: Capable of 0.02% (constant operation conditions with 700SP meters & mechanical registration, using 1 CPS test fluid)
- Viscosity: Will accurately measure liquids up to 1,500,000 SSU (325,000 CPS)
- Temperature: - 40 to 160°F (- 40 to 71°C)
Flange Connections:
The 700 1.5" rotary flow meter is engineered to meter liquid at up to 60 GPM (227 LPM).
Flange Connections:
The 700 2" rotary flow meter is engineered to meter liquid at up to 100 GPM (380 LPM).
Flange Connections:
The 700 3" rotary flow meter is engineered to meter liquid at up to 200 GPM (760 LPM).
Flange Connections:
The 700 4" rotary flow meter is engineered to meter liquid at up to 500 GPM (1,893 LPM).
NPT flanges are standard. BSPT, Slip Weld, ANSI and others available upon request
Don't see the regulatory approval you need? Contact us. TCS is continually adding to this list. Approvals could be available for a comparable meter, in final approval stages, or simply not added to the website yet.
European Union MID
Indian Legal Metrology
Indonesian Direktorat Metrologi
National Institute of Standards and Technology (NIST)/NTEP
New Zealand Ministry of Business, Innovation and Employment (MBIE)
South Korea Meter and Petrochemical Testing and Research Institute
The following accessories are compatible with TCS 700 Standard Petroleum (SP) Meters.
-
TCS 3000 Electronic Register
The TCS 3000 is a powerful, electronic register designed to transform the way you deliver fuel. It has been engineered to control most vehicle delivery operations. -
Mechanical Registration
This rugged, precise mechanical meter register is designed for all kinds of liquid inventory and delivery operations. This register totalizes and displays high-speed deliveries and transactions in large, easy-to-read figures. It features a highly... -
Pulse Transmitter
TCS pulse transmitters allow you to send volume data to a remote display, register, computer, or fuel management system (PLC). The glandless pulse transmitter can provide single or dual channel output.The DMP pulse transmitters provide accurate... -
740 Air Eliminator & Strainer
- Information
- Available for Sizes: 2", 3", 4"
A float and valve design senses and removes free air before it can enter the flow meter. Required for custody transfer applications to ensure the most precise measurement. -
745 High Volume Air Eliminator & Strainer
- Information
- Available for Sizes: 2", 3"
An offset 90° strainer and air eliminator assembly designed for use in applications where a high volume of free air may potentially enter the measurement system. Recommended for mobile fuel delivery systems to pass product depletion (split... -
747 Bulk Air Eliminator
- Information
- Available for Sizes: 3", 4"
A bulk air eliminator assembly is designed for use in applications where a high volume of free air may enter the measurement storage system. Available with single or dual SP, AF or SS air eliminators and assembled to carbon steel or stainless steel... -
748 Air Eliminator/Strainer (Electronic)
- Information
- Available for Sizes: 2", 3", 4"
An electronic controlled float switch and strainer assembly is designed to sense and remove free air before it can enter the flow meter. Efficiently removing air from the truck delivery while minimizing the amount of the residual product released... -
749 Air Eliminator / High Volume Strainer (Electronic)
- Information
- Available for Sizes: 2", 3"
An electronic controlled float switch and high volume strainer assembly designed to sense and remove free air before it can enter the flow meter. Efficiently removing air from the truck delivery while minimizing the amount of residual product... -
655 Electronic Control Valve
- Information
- Available for Sizes: 1.5", 2"
A normally closed two-stage diaphragm preset valve for use with electronic relay control. Stainless steel or brass pilot valves are available. Dimensionally interchangeable with the 650 Hydraulic Preset Valves. -
750 Hydraulic Preset Valve
- Information
- Available for Sizes: 1.5", 2", 3", 4"
A normally closed, hydraulically balanced piston control valve allows for auto-batch preset deliveries. The right-angle, two-stage control valve is mechanically linked to Veeder Root Preset Counter. -
755 Electronic Preset Valve
- Information
- Available for Sizes: 1.5", 2", 3"
A normally closed two-stage piston preset valve for use with electronic relay control. Stainless steel or brass pilot valves are available. Dimensionally interchangeable with the 750 Hydraulic Preset Valves. -
760 Air Check Valves
- Information
- Available for Sizes: 2", 3"
The air check valve operates on differential pressure, closing when air is present. Designed to increase air eliminator efficiency during product depletion.
